Music and recording garden rooms — acoustic isolation, treatment and HVAC noise

Roughly one in twenty of our commissions is for a music or recording space — sometimes a professional producer's home studio, sometimes a working musician's practice room, occasionally a serious hi-fi listening room. All three briefs share the same core problem: sound wants to escape, and it wants to bounce around inside the room in ways that flatter neither the music nor the neighbours. This is the working brief.

Isolation — keeping sound in (and out)

The single most important spec choice is the mass-spring-mass isolation strategy for the walls, floor and ceiling. A standard SIP shell is a decent starting point — mass, absorption, mass — but a serious recording brief needs the mass and the decoupling stepped up.

• — 01Wall assembly: 142 mm SIP outer skin + 100 mm resilient bar-mounted inner stud wall + 30 mm acoustic mineral wool + 2 × 15 mm high-density acoustic plasterboard. STC 55-60, which cuts a drum kit from painful to 'clearly audible but not disturbing' at 5 m outside.
• — 02Ceiling: Same treatment, resilient-mounted, with a floated inner ceiling on isolation hangers.
• — 03Floor: Floating floor deck on 25 mm acoustic isolation pads over the structural deck. Cuts impact transmission from bass amps and drum-kick.
• — 04Door: Twin-door acoustic set (sealed inner door + sealed outer door with a 500 mm airlock between). Standard doors leak sound catastrophically.

Room dimensions — avoiding the parallel-wall trap

The single most common recording-room mistake is a room where all opposing walls are exactly parallel. Parallel walls create standing waves at frequencies dictated by the room dimensions — modes — that make certain notes loud, others quiet, and mixing decisions unreliable.

For a serious recording room we non-parallel one pair of walls by roughly 3-6°. It's imperceptible visually and structurally trivial (SIP panels tolerate the geometry easily) but it kills modal build-up completely. For a listening room where a proper stereo image matters, we non-parallel both pairs of walls if the plot allows.

Golden ratios for room dimensions:

• — 01Bolt ratios (1 : 1.14 : 1.39). A 2.5 m height room would want to be 2.85 × 3.48 m. Rounds to 3.0 × 3.5 m externally for a small vocal or listening booth.
• — 02Sepmeyer ratios (1 : 1.28 : 1.54). A 2.6 m height room would be 3.33 × 4.00 m. Rounds to 3.5 × 4.2 m externally for a modest tracking room.
• — 03For a full drum room, 5.0 × 4.0 m external with a 3.0 m ceiling is where the modal problems become manageable without extreme treatment.

Acoustic treatment

Isolation stops sound leaving; treatment shapes the sound inside. A well-treated recording room has:

• — 01Broadband absorption — 4-8 large panels of 100 mm rockwool or dedicated acoustic foam at first-reflection points. Kills flutter echo and early reflection smearing.
• — 02Bass traps in the front corners — 200 mm+ depth rockwool or specific-tuned membrane traps. Modes below 200 Hz are where amateur rooms fail.
• — 03Diffusion on the rear wall — quadratic residue diffusers or a simple bookshelf-with-varied-depths. Preserves the room's ambient sense without smearing the mix.
• — 04A treated ceiling cloud above the mixing position — usually a large 100 mm absorber, fabric-wrapped.

Mechanical noise — the invisible enemy

Recording rooms fail on mechanical noise long before they fail on isolation. Standard extractor fans, standard heat pumps, standard MVHR systems — all noisy enough to ruin a vocal take. Our default recording-room spec:

• — 01Heat pump — dedicated silent-spec model (Mitsubishi MSZ-LN or equivalent), located on the far exterior wall, wall-mounted with anti-vibration bushings. Runs at 19 dB(A) at listener position when idle, 22 dB(A) at low fan speed.
• — 02MVHR — decoupled with in-duct silencers, running at low speed continuously.
• — 03No trickle vents (they whistle in wind, and they're an isolation leak). Ventilation goes through MVHR only.
• — 04Isolated cable trunking and cable-tray fixings — no direct mechanical contact between structural elements.

“A recording space fails on the small things. Mechanical noise, uninsulated duct penetrations, one leaky door gasket. The isolation spec matters, but the mechanical detail matters as much.”

— Arden & Oak — design lead

What it costs

The uplift over a standard 4.2 × 3.2 m garden room to a serious recording spec — twin-door acoustic set, mass-spring-mass wall assembly, floating floor, silent HVAC, acoustic treatment — is £6,500-11,000 depending on ambition. It's a substantial premium, but it's the difference between a room where you can actually record and one where you can't.
